Evolis AvansiaEvolis AvansiaEvolis Avansia
Avansia card printer
The premium retransfer printer for high definition cards
Printing:Single-sided, Double-sided
Encoding:Magnetic stripes, Smart contact, Smart contactless
Card lifespan:1-3 years
Number of cards per year:More than 30,000
Card security level:High
General features
Reverse transfer printing, using color dye sublimation and resin monochrome retransfer
Dual-sided printing (standard)
Over the edge printing
Using color dye sublimation and resin monochrome retransfer
600 dpi print head (23.6 dots/mm)
Bitmap: 24 bits, 16 million colors
Printout: Y/M/C 256 level
64 MB of memory (RAM)
Printing performances1
Full card:
Single side (YMCK): 25 s/card - 144 cards/hour
Dual side (YMCKK): 37.5 s/card - 96 cards/hour
Additional encoding modules
Available modules:
Magnetic stripe encoder ISO 7811
Dual contact and contacless encoder
Encoder connectivity: internal USB hub, 1 port available
Encoding options can be combined
Factory installed or installed on site for contact and contactless encoders
Interfaces
USB (1.0, 1.1, 2.0, 3.0), cable supplied
Ethernet TCP-IP 10BaseT, 100BaseT (Traffic Led)
Safety
RFID locking key
Support for security lock (Kensington® type)
Centralized locking system to secure access to blank cards, ribbon and film (optional)2
IPSec encrypted networking security
Card management and specifications
Card feeder: 250 cards (0.76 mm – 30 mil)
Card output hopper: 250 cards (0.76 mm – 30 mil)
Reject tray capacity: 30 cards (0.76 mm – 30 mil)3
Card thickness: 0.76 mm (30 mil), manual adjustment
Card types:
PVC cards
Composite PVC cards
PET-F cards
PET-G cards
Polycarbonate cards (PC)
ABS cards
Card format: ISO CR80 - ISO 7810 (53.98 x 85.60 mm – 3.370” x 2.125”)
Evolis High Trust® Ribbons
To maximize the quality and durability of printed cards, the lifespan of the print head and the overall printer reliability, use Evolis High Trust® ribbons.
Ribbon capacity:
Clear transfer film: 500 prints/roll
Holographic transfer film: 400 prints/roll
YMCK: 500 prints/roll
YMCKK: 400 prints/roll
YMCKI ribbon (for smart cards, magnetic stripes and signature panels): 400 prints/roll
YMCKH ribbon (for non PVC cards): 400 prints/roll
YMCFK ribbon (F = UV ink): 400 prints/roll
Software
Compatible with Windows (32/64 bits): XP SP3, Vista,W7, W8, W10
Delivered with cardPresso XXS for designing and editing badges
Internal database (unlimited records)
Windows® (from XP onwards)
Display
Two-line LCD display and LED status indicator
Printer graphical notifications: empty input hopper, empty/low level ribbon alert...
Certifications and statement of compliance
RoHS
CE, FCC, UL, IEC
Size and weight
Dimensions (H x W x D): 436 x 340 x 297 mm (17.16” x 13.38” x 11.69”)
Weight: 20 kg (44.09 lbs)
Warranty4
3 years for printer, lifetime warranty on print head
